What to Expect from

HTTP/2

Mark Nottingham (@mnot)

Why Change HTTP?

The Web Has Changed.

Web Engineering Today:
Current Perf Techniques

Spriting

Inlining

#globalheader { background:#707070;
  	background:
  		-o-linear-gradient(top, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) 5%, rgba(0, 0, 0, 0) 97%, rgba(0, 0, 0, .45) 100%),
  		-o-linear-gradient(left, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) .2%, rgba(0, 0, 0, 0) 99.8%, rgba(0, 0, 0, .2) 100%),
  		-o-linear-gradient(bottom, #666 0, #5e5e5e 50%, #707070 51%, #808080 100%)
  	;
  	background:
  		-moz-linear-gradient(top, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) 5%, rgba(0, 0, 0, 0) 97%, rgba(0, 0, 0, .45) 100%),
  		-moz-linear-gradient(left, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) .2%, rgba(0, 0, 0, 0) 99.8%, rgba(0, 0, 0, .2) 100%),
  		-moz-linear-gradient(bottom, #666 0, #5e5e5e 50%, #707070 51%, #808080 100%)
  	;
  	background:
  		-webkit-gradient(linear, 0 0, 0 100%, from(rgba(0, 0, 0, .2)), color-stop(0.05, rgba(0, 0, 0, 0)), color-stop(0.97, rgba(0, 0, 0, 0)), to(rgba(0, 0, 0, .45))),
  		-webkit-gradient(linear, 0 0, 100% 0, from(rgba(0, 0, 0, .2)), color-stop(0.002, rgba(0, 0, 0, 0)), color-stop(0.998, rgba(0, 0, 0, 0)), to(rgba(0, 0, 0, .2))),
  		-webkit-gradient(linear, 0 100%, 0 0, from(#666), color-stop(0.5, #5e5e5e), color-stop(0.51, #707070), to(#808080))
  	;
  }

Apple

Sharding

YouTube

Concatenation

Hacks.

“Eliminate Requests”

Why Are HTTP Requests

So Expensive?

1. HTTP/1 Uses TCP Poorly.

htracr

Head of Line Blocking

One outstanding request per connection
Even with pipelining, a big / slow response will block
State of the Art: Use 4-8 connections

TCP Slow Start

Congestion Control is your Friend.

Summary: HTTP Uses Multiple Connections

Connections don't see full utilisation
Increases chances of congestion events
Resource-intensive on server; n sockets
All of this is really tricky for clients

HTTP flows are short and bursty.

TCP was built for long-lived flows!

2. HTTP Headers Are Verbose


GET / HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/*;q=0.8
DNT: 1
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

525 bytes


GET /assets/dist/js/etsy.recent-searches.20121001205006.js HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: */*
DNT: 1
Referer: http://www.etsy.com/
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: autosuggest_split=1; etala=111461200.1476767743.1349274889.1349274889.1349274889.1.0; etalb=111461200.1.10.1349274889; last_browse_page=%2F; uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

226 new bytes; 690 total


GET /assets/dist/js/jquery.appear.20121001205006.js HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: */*
DNT: 1
Referer: http://www.etsy.com/
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: autosuggest_split=1; etala=111461200.1476767743.1349274889.1349274889.1349274889.1.0; etalb=111461200.1.10.1349274889; last_browse_page=%2F; uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

14 new bytes; 683 total


GET /assets/dist/js/bootstrap/username-suggester.20121001205006.js HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: */*
DNT: 1
Referer: http://www.etsy.com/
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: autosuggest_split=1; etala=111461200.1476767743.1349274889.1349274889.1349274889.1.0; etalb=111461200.1.10.1349274889; last_browse_page=%2F; uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

28 new bytes; 698 total

Four Requests
2,596 bytes total
~3 packets in most places
1,797 redundant bytes

Patrick’s Test

83 asset requests
Initial Window = 3
~1,400 bytes of headers
7-8 Round Trips

Big req * many reqs / small IW = SLOW

What is HTTP/2?

SPDY was the starting point

chrome://net-internals/#spdy

More than 35 Implementations

(nothing new here)

It is expected that HTTP/2.0 will:

Substantially and measurably improve end-user perceived latency in most cases, over HTTP/1.1 using TCP.
Address the "head of line blocking" problem in HTTP.
Not require multiple connections to a server to enable parallelism, thus improving its use of TCP, especially regarding congestion control.
Retain the semantics of HTTP/1.1, leveraging existing documentation (see above), including (but not limited to) HTTP methods, status codes, URIs, and where appropriate, header fields.
Clearly define how HTTP/2.0 interacts with HTTP/1.x, especially in intermediaries (both 2->1 and 1->2).
Clearly identify any new extensibility points and policy for their appropriate use.

HTTPbis Charter

Goal: One TCP Connection

TCP likes longer-lived flows
Less resource-intensive
More fair

1. Separate Semantics
from Framing


HTTP/1.1 200 OK
Server: nginx
Date: Wed, 06 Mar 2013 03:41:55 GMT
Content-Type: text/html
Transfer-Encoding: chunked
Connection: keep-alive
Set-Cookie: CG=US:TX:San+Antonio; path=/
Last-Modified: Wed, 06 Mar 2013 03:41:03 GMT
Vary: Accept-Encoding
Cache-Control: max-age=60, private
Expires: Wed, 06 Mar 2013 03:42:48 GMT
Content-Encoding: gzip

HTTP/2 Header

HTTP/2 Frame Types

HTTP Request + Response

Multiplexing

Priortisation

&

Flow Control

2. Header Compression

First Try: GZIP

One compression context for all headers in each direction
Very efficient, easy to implement
Some memory overhead

CRIME

Compression inside encryption where the attacker can inject data

HPACK: Safe, Smart Header Compression

Coarse-grained delta coding

https://http2.github.io/http2-spec/compression.html

3. Server Push

How will HTTP/2 Affect Me?

It'll be Easier to go Fast.

…according to Google…

time from first request byte to onload event in the browser

…and Twitter

raw request latency

Google Developer Blog

HTTP semantics won’t change…

But, leaked abstractions will.

Less “Best Practices” for Perf

inlining

spriting

concatenating

sharding

Rethink Connection Handling

Load Balancers
Failover
Timeouts

Use TLS

All major browsers require it.
Firefox supports "Opportunistic Security" for HTTP URLs

Debugging

Now a binary format :(
... but we do have a Wireshark plugin, h2i, and more coming.
