HTTP/2.0 Update

Mark Nottingham   (@mnot)



IETF HTTPbis
Working Group

Who?



IETF ≠ Corporate Consensus

“Rough Consensus &
Running Code”

...among individual engineers.

No concept of membership, as such.

Why?

The Web Has Changed.

Heavier and More Interactive

HTTP Archive

Performance = Attention = $$$

Courtesy Ilya Grigorik

Mobile Is Here

Courtesy Ilya Grigorik

Performance is Important.

Web Engineering Today

Spriting


Inlining

#globalheader { background:#707070;
  	background:
  		-o-linear-gradient(top, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) 5%, rgba(0, 0, 0, 0) 97%, rgba(0, 0, 0, .45) 100%),
  		-o-linear-gradient(left, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) .2%, rgba(0, 0, 0, 0) 99.8%, rgba(0, 0, 0, .2) 100%),
  		-o-linear-gradient(bottom, #666 0, #5e5e5e 50%, #707070 51%, #808080 100%)
  	;
  	background:
  		-moz-linear-gradient(top, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) 5%, rgba(0, 0, 0, 0) 97%, rgba(0, 0, 0, .45) 100%),
  		-moz-linear-gradient(left, rgba(0, 0, 0, .2) 0, rgba(0, 0, 0, 0) .2%, rgba(0, 0, 0, 0) 99.8%, rgba(0, 0, 0, .2) 100%),
  		-moz-linear-gradient(bottom, #666 0, #5e5e5e 50%, #707070 51%, #808080 100%)
  	;
  	background:
  		-webkit-gradient(linear, 0 0, 0 100%, from(rgba(0, 0, 0, .2)), color-stop(0.05, rgba(0, 0, 0, 0)), color-stop(0.97, rgba(0, 0, 0, 0)), to(rgba(0, 0, 0, .45))),
  		-webkit-gradient(linear, 0 0, 100% 0, from(rgba(0, 0, 0, .2)), color-stop(0.002, rgba(0, 0, 0, 0)), color-stop(0.998, rgba(0, 0, 0, 0)), to(rgba(0, 0, 0, .2))),
  		-webkit-gradient(linear, 0 100%, 0 0, from(#666), color-stop(0.5, #5e5e5e), color-stop(0.51, #707070), to(#808080))
  	;
  }

Apple

Sharding

YouTube

Concatenation





Hacks.

Mantra:

“Eliminate Requests”

Why Are HTTP Requests

So Expensive?

1. HTTP/1.x Uses TCP Badly.


htracr

Head of Line Blocking

  • Usually, one outstanding request per connection
  • Even with pipelining, a big / slow response blocks
  • State of the Art: Use 4-8 connections

Multiple Connections

  • Result? HTTP/1 tends towards short, bursty flows
  • TCP Slow Start means full throughput not seen
  • Resource-intensive on server; n sockets
  • Increases chances of congestion events
    • ... made worse by Buffer Bloat
  • All of this is really tricky for clients

2. HTTP Headers Are Verbose


GET / HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/*;q=0.8
DNT: 1
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

525 bytes


GET /assets/dist/js/etsy.recent-searches.20121001205006.js HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: */*
DNT: 1
Referer: http://www.etsy.com/
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: autosuggest_split=1; etala=111461200.1476767743.1349274889.1349274889.1349274889.1.0; etalb=111461200.1.10.1349274889; last_browse_page=%2F; uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

226 new bytes; 690 total


GET /assets/dist/js/jquery.appear.20121001205006.js HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: */*
DNT: 1
Referer: http://www.etsy.com/
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: autosuggest_split=1; etala=111461200.1476767743.1349274889.1349274889.1349274889.1.0; etalb=111461200.1.10.1349274889; last_browse_page=%2F; uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

14 new bytes; 683 total


GET /assets/dist/js/bootstrap/username-suggester.20121001205006.js HTTP/1.1
Host: www.etsy.com
User-Agent: Mozilla/5.0 (Macintosh; Intel Mac OS X 10_8_2) AppleWebKit/536.26.14 (KHTML, like Gecko) Version/6.0.1 Safari/536.26.14
Accept: */*
DNT: 1
Referer: http://www.etsy.com/
Accept-Language: en-us
Accept-Encoding: gzip, deflate
Cookie: autosuggest_split=1; etala=111461200.1476767743.1349274889.1349274889.1349274889.1.0; etalb=111461200.1.10.1349274889; last_browse_page=%2F; uaid=uaid%3DVdhk5W6sexG-_Y7ZBeQFa3cq7yMQ%26_now%3D1325204464%26_slt%3Ds_LCLVpU%26_kid%3D1%26_ver%3D1%26_mac%3DlVnlM3hMdb3Cs3hqMVuk_dQEixsqQzUlNYCs9H_Kj8c.; user_prefs=1&2596706699&q0tPzMlJLaoEAA==
Connection: keep-alive

28 new bytes; 698 total

  • Four Requests
  • 2,596 bytes total
  • ~3 packets in most places
  • 1,797 redundant bytes

Patrick’s Test

  • 83 asset requests
  • IW = 3
  • ~1,400 bytes of headers
  • 7-8 Round Trips


Big req * many reqs / small IW = SLOW

What


http://http2.github.io/http2-spec/

SPDY was the starting point


chrome://net-internals/#spdy

(nothing new here)

It is expected that HTTP/2.0 will:

  • Substantially and measurably improve end-user perceived latency in most cases, over HTTP/1.1 using TCP.
  • Address the "head of line blocking" problem in HTTP.
  • Not require multiple connections to a server to enable parallelism, thus improving its use of TCP, especially regarding congestion control.
  • Retain the semantics of HTTP/1.1, leveraging existing documentation (see above), including (but not limited to) HTTP methods, status codes, URIs, and where appropriate, header fields.
  • Clearly define how HTTP/2.0 interacts with HTTP/1.x, especially in intermediaries (both 2->1 and 1->2).
  • Clearly identify any new extensibility points and policy for their appropriate use.

HTTPbis Charter

Goal: One TCP Connection

  • TCP likes longer-lived flows
  • Less resource-intensive
  • More fair

1. Separate Semantics
from Framing


HTTP/1.1 200 OK
Server: nginx
Date: Wed, 06 Mar 2013 03:41:55 GMT
Content-Type: text/html
Transfer-Encoding: chunked
Connection: keep-alive
Set-Cookie: CG=US:TX:San+Antonio; path=/
Last-Modified: Wed, 06 Mar 2013 03:41:03 GMT
Vary: Accept-Encoding
Cache-Control: max-age=60, private
Expires: Wed, 06 Mar 2013 03:42:48 GMT
Content-Encoding: gzip

HTTP/2 Header

HTTP/2 Header

(Some) Frame Types

  • DATA
  • HEADERS
  • SETTINGS
  • RST_STREAM
  • GOAWAY

SETTINGS

  • SETTINGS_MAX_CONCURRENT_STREAMS
  • SETTINGS_FLOW_CONTROL_OPTIONS
  • SETTINGS_INITIAL_WINDOW_SIZE

Priortisation

&

Flow Control


  • Priority field
  • WINDOW_UPDATE frame
  • Session level and stream level control

2. Header Compression

First Try: GZIP

  • One compression context for all headers in each direction
  • Very efficient, easy to implement
  • Some memory overhead

CRIME

Compression inside encryption where the attacker can inject data

HPACK: Safe, Smart Header Compression

Coarse-grained delta coding


http://http2.github.io/http2-spec/compression.html

3. Server Push

Where are We?

  • nghttp2; C; client + server + intermediary; NPN + Upgrade + direct; draft-06
  • http2-katana; C#; server + test client; ALPN + Upgrade; draft-06
  • node-http2; JavaScript (NodeJS); server + client; NPN + direct; draft-06
  • Mozilla; C++; client; ALPN + NPN; draft-06
  • http2-perl; Perl; client + server; NPN; draft-04
  • iij-http2; NodeJS; client + server; ALPN + NPN + Upgrade + direct; draft-06
  • Akamai Ghost; C++; intermediary; NPN; draft-06
  • Chromium; C++; client; ALPN + NPN; draft-06
  • Hasan's GFE; C++; intermediary; ALPN + NPN; draft-04
  • Twitter; Java; server + client; NPN; draft-06
  • Wireshark; C; other; NPN + ALPN; draft-06

How will HTTP/2 Change the Web?

HTTP semantics won’t change…

But, leaked abstractions will.

Better “RESTful” HTTP APIs

  • Fine-grained without request overhead
  • “BATCH” operations no longer necessary
  • Headers can be more descriptive

Challenges

This is Standards

courtesy: XKCD

Getting from 1 to 2

  • HTTP is widely used
  • Implementations have great variance
  • Intermediaries are hard to replace

Upgrade Paths

  • HTTPS URLs:
  • HTTP URLs:
    • Inband Upgrade “dance”
    • DNS “hint” that HTTP/2 is available on another port

“Magic” as a Safety Net

Checking a ~.5% sample of active Web servers:

  • FOO\n\n - 4.5% time out
  • FOO * HTTP/2.0\r\n\r\nBAR\r\n\r\n - 0.45% time out

Getting the Most out of HTTP/2.0 will take Effort

  • When to Push?
  • Flow Control Tweaks
  • Prioritisation

No Longer Text-Based

Upcoming Work

HTTP/2 and Encryption

From a protocol standpoint, these are all passive attacks

Opportunistic Encryption for "http://" URIs

That's Great, But...

  • Certificate Authorities are broken
  • Client Trust Model is naive

Fixing TLS Man-in-the-Middle

... by "pinning" the key:

... or, by logging:

Proxies

  • Network operators often interpose proxies
  • Proxy operation in HTTP isn't well-specified
  • As a result, sometimes you don't know who you're talking to
  • Push towards encryption is surfacing these issues

WebSockets over HTTP/2.0

Moving Past TCP

Fixing HTTP just makes TCP's limits more apparent.

Find Out More
